Performance Tests
8648B Test Record
RF Level Accuracy performance test is not required.
NOTE If the automated Power Level Accuracy performance test is performed, the
RF Level Accuracy performance test is not required.
Table 8-40. RF Level Accuracy Performance Test with Option 1EA and 1E6 -
Part 3
Frequency
(MHz)
Amplitude
(dBm)
Limits (dBm)
Uncertainty
(±dB)Lower Measured Upper
3.0 13 11.5 14.5 0.23
249.9 18 16.5 19.5 0.23
400 18 16.5 19.5 0.23
999.9 18 16.5 19.5 0.23
1500 17 15.5 18.5 0.23
Table 8-41. RF Level Accuracy Performance Test - Part 4
Frequency
(MHz)
Amplitude
(dBm)
Limits (dBm)
Uncertainty
(±dB)Lower Measured Upper
2000 −25.9 −26.9 −24.9 0.16
−35.9 −36.9 −34.9 0.16
−45.9 −46.9 −44.9 0.16
−55.9 −56.9 −54.9 0.16
Table 8-42. Pulse Modulation On/Off Ratio Performance Test Option 1E6
Frequency
(MHz)
Limits (dB)
Uncertainty
(±dB)Measured Upper
100 80 1.8
500 80 2
1000 80 2
1500 80 2
2000 80 2
