Agilent Technologies 8648A User Manual

8-146
Performance Tests
8648D Test Record
NOTE If the automated Power Level Accuracy performance test is performed, the
RF Level Accuracy performance test is not required.
Table 8-91. RF Level Accuracy Performance Test - Part 4
Frequency
(MHz)
Amplitude
(dBm)
Limits (dBm)
Uncertainty
(±dB)Lower Measured Upper
2000 −25.9 −26.9 −24.9 0.16
−35.9 −36.9 −34.9 0.16
−45.9 −46.9 −44.9 0.16
−55.9 −56.9 −54.9 0.16
2499 −25.9 −26.9 −24.9 0.16
−35.9 −36.9 −34.9 0.16
−45.9 −46.9 −44.9 0.16
−55.9 −56.9 −54.9 0.16
3200 −25.9 −27.4 −24.4 0.19
−35.9 −37.4 −34.4 0.19
−45.9 −47.4 −44.4 0.19
−55.9 −57.4 −54.4 0.19
3200 −25.9 −27.9 −23.9 0.21
−35.9 −37.9 −33.9 0.21
−45.9 −47.9 −43.9 0.21
−55.9 −57.9 −53.9 0.21
