Agilent Technologies B1500A Self-Paced Training Manual

3-8
Graph Analysis Tools
Line control
active line (normal line)
active cursor
cursor
marker
line (tangent line)
Line control:
Line 1 State icon enables or disables line 1 and its function: normal, gradient, tangent, or
regression.
Line 2 State icon enables or disables line 2 and its function: normal, gradient, tangent, or
regression.
Cursor to Marker icon moves the cursor to the marker position.
Adjust Gradient icon is available when a regression line is active. Clicking this icon enables the
rotary knob and the mouse wheel to increase/decrease the gradient of the line. Clicking this icon
again, clicking the rotary knob, or clicking the mouse wheel disables this function.
