Agilent Technologies PlateLoc User Manual

Chapter 3: Getting started
PlateLoc User Guide
56
d. Pull the card through the PlateLoc so that the end of the seal is
past the plate stage.
4. Press the silver close-gripper button on the back of the PlateLoc until
it clicks. The red open-gripper button pops back up.
Pressing the silver button closes the gripper and holds the seal in
place inside the device.
00203
PlateLoc
remove loading card
00203
00210
PlateLoc
Loading card removal
00210
00191
PlateLoc
connections
00191
PlateLoc
connections
Press to hold the seal in place.
