4 Basic Operation
Spectrum window
67 Agilent Triple Quadrupole LC/MS System User Guide
To add other MS signals, such as EICs, setpoints, and actuals, select these on the
TQ tab in the Method Editor window.
3 Click OK to close the Edit Signal Plot dialog box.
Spectrum window
This window displays the spectral plot in real time. Additional tabs are displayed
for other modules.
Method Editor window
In this window, enter acquisition parameters for the method. Tune values are
displayed on the Autotune tab.
