2
.
Installation
ANET3910-EN Us
ers Manual
9
2.2.1.5
DC Powe
r IN connector
The DC Power in plug is a DC panel socket with a 2,5mm centre pin.
The nominal input voltage is 12V DC via the centre pin..
2.2.1.6
RJ4
5 Ethernet connector
For the Ethernet connection a standard RJ45 plug is provided at the back panel.
Figure 2-6 DC pane
l socket
18
20
