9 APPENDIX
9.1 ANET Table Adapter Panel
For the ANET3910- D Module Variants (housing with docking station back panel), a
back panel adapter for table operation is available, which is shown below:
Figure 9.1-1 ANET Table Adapter Pinout
DC panel socket
Auxiliary connector
Mechanical lock screw and Emergency Boot button
ON/OFF button
USB HOST connector
Ethernet connector
9.1.1 How to connect the ANET Table Adapter
Figure 9.1-2 ANET Docking Connector
Step1:
Figure 9.1-3 ANET Table Adapter
