Aim STANAG3910 - Certificate of Volatility

ANET3910-EN User’s Manual
58
9.2 Certificate of Volatility
Model: ANET3910-EN
Part-Number: 13E25-0100
Manufacturer: AIM GmbH
Sasbacher Str. 2
D-79111 Freiburg
Germany
Volatile Memory
Does the item contain volatile memory (i.e., memory whose contents are lost when power is removed)?
Yes No
Description of used volatile memory:
Type:
SSRAM
Size:
16 MByte
User Modifiable:
Yes
No
Function:
Buffers, Descriptors,
Global RAM
Process to Sanitize:
Power off / on
(Power Cycle)
Type:
DDR3-RAM
Size:
1 GByte
User Modifiable:
Yes
No
Function:
ASP Program
Process to Sanitize:
Power off / on
(Power Cycle)
Non-Volatile Memory
Does the item contain non-volatile memory (i.e., memory whose contents are retained when power is removed)?
Yes No
Description of used non-volatile memory:
Type:
Serial SPI-Flash
Size:
8 Mbit
User Modifiable:
Yes
No
Function:
LS-BIU
Processor Boot
Process to Sanitize:
Erase
Type:
Serial EEPROM
Size:
1 kByte
User Modifiable:
Yes
No
Function:
NOVRAM for
board personalization
Process to Sanitize:
Erase
Type:
NAND-Flash
Size:
512
MByte
User Modifiable:
Yes
No
Function:
LINUX Program & Data
Firmware
Process to Sanitize:
Erase
Media
Does the item contain media storage capability (i.e., removable or non-removable disk drives, tape drives, memory cards, etc.)?
Yes No
Description of used media storage:
Type:
-None-
Size:
-
User Modifiable:
Yes
No
Function:
-
Process to Sanitize:
-
Additional Information:
Test Engineer
Name:
Frank Scherer
Title:
Hardware Engineer
Date of Certification:
11.07.2016
All operating Data for handling the I/O Protocol will be stored in volatile memory only.
No Transfer data is stored in Non-Volatile Memory. The Non-Volatile Memory only
contains production relevant data for board personalization, FPGA Logic or Firmware
Code for the on board Microcontroller.
