ANET3910-EN User’s Manual
2.2.2 Module-Powering and Status Indication (LED’s)
2.2.2.1 Ethernet RJ45 Status Indicator
On the RJ45 connector two status LEDs are implemented. One LED for Link and
Activity status (yellow) and the other LED one for the speed detection (green).
2.2.2.2 Module Status Indicator
On top of the ANET3910-EN cover, the transparent AIM Logo is illuminated and
indicates the status from the ANET3910-EN as following:
Power ON/OFF / Normal operation
1) LED = RED illuminated
Illuminated during power on cycle
2) LED = BLUE fast pulsing
Fast pulsing blue during ASP / LINUX boot up
3) LED = BLUE slow pulsing
Slow pulsing blue when the on board OS has been boot up (ready for operation)
4) LED = RED fast pulsing
Fast pulsing red during ASP / LINUX shutdown (power off) cycle and during re-
boot commanded via the ANET Web Configuration tool
Emergency- / Maintenance- Mode (e.g. running an update)
1) LED = RED fast pulsing
Fast pulsing red during re-boot OS to Maintenance-Mode and during an update
cycle is running
2) LED = RED slow pulsing:
If OS is in Maintenance-Mode
