12.15 HydroSens™ AHU - nozzle rack PA and bulkhead
12. Spareparts & Consumables
Pos. Part no. Description Pos. Part no. Description
1 763929 Screw hex cap M6x60 PA 6 160100 Sliplock HP straight ø4 – 1/4”
2 763932 Washer lock ø6 A2 7 182351 Nozzlecarrier HydroFlex PA
3 486529 Pipe clamp, black ø16 mm 8 529568 Bulkhead 10 mm – 4 mm
4 763930 Nut knurled M6 PA 9 529564 Foot incl. nut
5 161110 T-ps 1/4” internal thread
