25
ø4 mm = R4 cm
ø10 mm = R10 cm
High pressure hose 4 mm hose 10 mm hose
Operating pressure at 23 ⁰C / 73 °F 88 bar / 1276 psi 66 bar / 957 psi
Operating pressure at 45 ⁰C / 113 °F 66 bar / 957 psi 50 bar / 725 psi
Q3, burst pressure at 23 ⁰C / 73 °F, min. 150 bar / 2175 psi 150 bar / 2175 psi
Outside/inside diameter mm ø4/ø2 ø10/ø6
Minimum bend radius cm/inch 4 / 1,6 10 / 4
Recomended hose length m/ft 0-3 / 0-10 See Chart
Max. hose length m/ft 5 / 16,5 See Chart
Material properties Polyamide 12 (PA 12-HL) black colour,
heat ageing stabilised, light stabilised.
4.10 Hoses
4. Datasheet
Minimum bend radius
201218
