UV 405 AL
4. Datasheet
4.7 UV, type 405 AL
Flow rate, max. l/min / gpm 19 / 5
UVC transmittance % at 1cm 99
UVC dose J/m² 300
Water temperature range °C/°F 5-50 / 41-122
Total power consumption W 33W
Installation position Vertical or horizontal
UV reactor:
Material Stainless steel 304 (optional 316L)
Connections 3/4” BSP male
Volume l/gal 1 / 0,3
Weight kg/lps 1,5 / 3,3
Working pressure, max. bar/psi 10 / 145
Protection class IP 54
Shape U
Flow direction From bottom to top
UV lamp:
Number of lamps 1
Lifespan hr 9000
Lamp power W 30
Type Low pressure, type 028102
Power supply:
Material Thermoplastic
Dimensions mm 118 x 60 x 64
Protection class IP 54
Ambielt temperature range °C/°F 5-45 / 41-113
Power supply V/Hz 230 V - 50/60 Hz
Lamp cable length m/inch 1 / 39”
Power supply cable length 1 / 39”
Feed plug SCHUKO (standard)
