4. Datasheet
Data sheet Installation cable
Max voltage 0,6/1 kv
Isolation XLPE
Max. operation temperature °C 90 °C
Max. short circuit temperatur °C 250 °C
Bending radius 8 x diameter
Cobber wire Class 1
Cover Copolymer, thermoplastic, UV-stable
4.11 Cables
At 2/4/6/8Amp load at X distance. Y conrms the voltage drop.
