4. Datasheet
4.8 Dosatron
Item No. 176520 176530
Type D07 RE 5 Compact D25 RE 2 VFP
Operating pressure bar/psi 0,3 - 6,0 / 4,4 - 87 0,3 - 6,0 / 4,4 - 87
Adjustable injection rate % 0,8 - 5,5 0,2 - 2
Adjustable injection ratio 1:128 - 1:20 1:500 - 1:50
Flow range l/h / gph 5-700 / 1,3-185 10-2500 / 2,6-660
Consentrate additive volume l/h / gph 0,8-38,5 / 0,2-10,2 0,02-50 / 0,05-13,2
Water temperature range °C/°F 5-40 / 41-104 5-40 / 41-104
Dosing rate 1 % = 1:100 1 % = 1:100
Average dosing accurancy ± 5 % ± 5 %
Repeatability API standard ± 3 % ± 3 %
Pressure loss bar/psi 0,3-1,4 / 4,3-20,3 0,3-1,9 / 4,3-27
Connection inlet/outlet 3/4” BSP-NPT male 3/4” BSP-NPT male
Suction selfpriming
Max. viscosity consentrate at 20 °C / 68 °F 400 cSt 400 cSt
Max. suction hight m/ft 4 / 13 4/ 13
Package size mm/inch 160 x 330 x 185 mm
6,3” x 13” x 7,3”
170 x 520 x 175 mm
6,7” x 7” x 20,5”
Package weight kg/lbs 1 / 2,2 1,85 / 4,0
