Airtec RO Plus l - Externalbox

76
Software/
rst zone no.
Maintenance password: 9963
pq
Zone control
pq
External stop
pq
Sensor oset
pq
Alarm limit %RH/
hysteresis
pq
Alarm in/
hygiene rinse
pq
User password: 1300
Puls/pause X1+X2
puls/pause X3
pq
Enable soaking /
o delay ext. start
pq
Hours
pq
Log
pq
High %RH alarm
or low %RH alarm
or alarm in
pq
Info. soaking /
o delay ext. start
pq
Frontpage
w. status
pq
%RH - zone X1 & X2
or
%RH/°C - zone X1
pq
%RH - zone X3
or
%RH/°C - zone X2
pq
Soaking time /
o delay time
pq
Password
pq
t
Date & time
t
u
1/9 I:
Inputs
t
u
2/9 Q:
Outputs
t
u
3/9 AI:
Analog inputs
t
u
4/9 to 8/9
Not used
t
u
9/9
Arrow screen
~
| }

u
Press ESC to access PLC menu to setup IP address and Date & Time
ESC+p=Start soaking
ESC+q=Reset alarm
9. Display Menu
9.5 ExternalBox
Display buttons
p = Up screen/value
q = Down screen/value
t = Previous screen/setting
u = Next screen/setting
ESC > 3 sec. = Enable edit mode
ESC = Cancel/exit edit mode
OK = Select setting/accept value
Display light
White = OK
Orange = Setup active
*
Orange ashing = Ext. stop active
*
Red ashing = Alarm
-Airtec Ext.Box-
Software V. 2.00
Ty pe: 3x%RH
St atus: OK
201218
