Airtec RO Plus l - Sensor

29
SmartSens
SmartSens
Power supply Vdc 12 to 24 Vdc
Max power consumption mA < 10 mA
Material Aluminium, polyamid tip and metal lter
Connection M12, 4 pole connector
Response time 10 sec.
Temperature range °C/°F -40 to +60 / -40 to 140
Resolution °C/°F 0,1 / 0,18
Accuracy -40 to 0 °C/-40 to 32 °F ± 1,5 °C / 2,7 °F
Accuracy 0 to 40 °C/32 to 104 °F ± 0,5 °C / 0,9 °F
Accuracy 40 to 60 °C/104 to 140 °F ± 1,5 °C / 2,7 °F
Repeatability °C/°F 0,1 / 0,18
Humidity range %Rh 0-100
Resolution % 0.1
Accuracy 0 to 90 % Rh ± 2 %
Accuracy 90 to 100 % Rh ± 4 %
Hysteresis %Rh ± 1 %
Long term stability per year < 1 %
Analog output 0 - 100 %RH and -40 - 60 °C 0-10 V DC
Dimensions (diameter x height) mm/inch ø20 x 125 mm / ø0,8” x 5”
Weight kg/lbs 0,06 / 0,13
SmartSens Wiring
4. Temp. Out 0-10 V 3. Hum. Out 0-10 V
2. Supply +24 V DC1. Supply -24 V DC
4. Datasheet
4.14 Sensor
