TROUBLESHOOTING
6) Check Mode
Check mode overwrites various stored data such as running hours, and checks operation of various parts.
Normally, use this mode with the procedure shown below.
1. Select command
1) Select the code number with [UP] or [DOWN] switch. Select the dip switch number or other with [INDOOR
UNIT] switch.
2) Proceed to "2. During command setting" with [SET] switch.
2. During command setting
1) Change the setting data with [UP] or [DOWN] switch and [SET] switch.
2) Command process is determined with [SET] switch. After determined, it proceeds to 1. Select command.
※Underlined items
may be unnecessary depending on the code number.
※Refer to P235 and after, [Code List for Each Mode] for available code numbers.
Function of each switch
Switch Display contents of functions / 7-segment LEDs
[UP] switch
1. Select command
Changes code number. The code number increases.
(00 → 01 → ··· → 7A → 7b → ··· → FE → FF → 00 → ··· )
2. During command setting
Changes the rated value. Increases the rated value.
※ Refer to P248 and after, [Operational Procedure / Display Con-
tents] operation method of each code for details.
[DOWN] switch
1. Select command
Changes code number. The code number decreases.
(FF → FE → ··· → 54 → 53 → ··· → 01 → 00 → FF → ··· )
2. During command setting
Changes the rated value. Decreases the rated value.
※ Refer to P248 and after, [Operational Procedure / Display Con-
tents] operation method of each code for details.
[INDOOR UNIT] switch
1. Select command
Changes the dip switch number, etc.
※ Refer to P248 and after, [Operational Procedure / Display Con-
tents] operation method of each code for details.
[MODE] switch
1. Select command, 2. During command setting
Switches the mode. The mode proceeds to running hours display mode
by pressing the switch for 1 second.
[CLEAR] switch
2. During command setting
Cancels the setting data.
(Switches: 2. During command setting → 1. Select command)
[SET] switch
1. Select command
Starts the command setting.
(Switches: 1. Select command → 2. During command setting)
2. During command setting
Changes the digit to be set during command setting.
Determines the setting data.
(Switches: 2. During command setting → 1. Select command)
※ Refer to P248 and after, [Operational Procedure / Display Con-
tents] operation method of each code for details.
Simultaneous pressing of
[UP] + [DOWN] switches
2. During command setting
Switches between forced setting / automatic setting.
※ Refer to P248 and after, [Operational Procedure / Display Con-
tents] operation method of each code for details.
