AISIN SEIKI E1 Series - Engine Coolant System

314
TECHNICAL DATA FOR REPAIR
3. Engine Coolant System
Item Standard value Remark
Thermostat valve
140℉(60 ℃)
open
Starts
opening at
140 ℉ (60 ℃ )
Opened
fully at
163 ℉ (73 ℃ )
Thermostat
valve lift
amount
0.33 inch (8.5 mm)
158℉(70 ℃)
open
Starts
opening at
158 ℉ (70 ℃ )
Opened
fully at
181 ℉ (83 ℃ )
Thermostat
valve lift
amount
0.33 inch (8.5 mm)
Engine coolant
Type AISIN Coolant S
Color Green
Amount
8 TON 14.99 l (15 L) Including engine
coolant in the
reserve tank
15 TON 26.01 l (26 L)
Volume concentration
50 vol% (engine coolant : 0.55,
water : 0.45)
-4 ℉ (-20 ℃ )
antifreezing solution
Engine coolant additive
Type AISIN Coolant additive
Specified
refilling
amount
8 TON 10.1 ~ 11.8 fl oz. (300 ~ 350 cm
3
)
15 TON 15.6 ~ 17.2 fl oz. (460 ~ 510 cm
3
)
Engine coolant pump
Resistance
value
8 TON 16 ~ 25 Ω
15 TON 10 ~ 18 Ω
