59
PERIODIC INSPECTION
26) Engine Startability Inspection
1. Crank the engine to check if the engine starts within 3 sets.
27) Engine Mount Replacement
[ 8 TON only ]
1. Check engine mount replacement location.
2. Place the jack from the rear at the location shown
right.
3. Set the wooden block on the jack.
4. Then jack up until the engine is lifted about 0.2 inch
(5 mm).
NOTE)
Be sure to jack up until the engine is lifted.
Be careful not to crush the harnesses on the base
panel.
5. Unscrew 4 bolts of rear side engine bracket.
Inspection interval Every 3 years (10,000 hours)
Engine mount
Engine mount (rear side)
(front side)
Wooden block
Jack
Bolts
Rear side
(4 pieces)
To Next Page
