97
REPLACEMENT OF MAIN COMPONENTS
3. Replacement of Cylinder Head
[Necessary items]
[ 8 TON ]
[Removal]
1. Drain engine coolant.
1) Clamp the engine coolant hoses at the outlet and
inlet ports of the radiator (2 places) with 2 hose
clippers.
2) Open the radiator cap.
3) Loosen the drain plug cap, and drain engine
coolant from the engine.
4) Remove the 2 engine coolant hoses from the
engine.
Part name Part No. Quantity
Parts
Set, Cylinder Head ASSY
See parts catalog
1
AISIN Coolant S 1
AISIN Gas Engine Oil L-10000G Small amount
Clamping positions
Radiator cap
Drain plug
Engine coolant hoses
To Next Page
