66
REPLACEMENT OF MAIN COMPONENTS
3. Remove the engine coolant pump.
1) Unscrew 2 bolts to remove the cover.
2) Unscrew 2 bolts to remove the engine coolant
pump.
4. Loosen the drain plug cap, and drain engine coolant
from the engine.
NOTE) It makes draining easier to insert a hose with
approximately 1/4 inch (7 mm) inner diameter
into the drain plug.
5. Remove the under engine parts.
1) Unscrew 2 bolts to remove the 2 oil stays.
2) Unscrew 2 bolts to remove the cover. Remove the
oil level switch.
3) Unscrew 2 bolts to remove the stay.
Bolts
Bolts
Drain plug
Bolts
Stay
Bolts
Bolts
Cover
To Next Page
