Akai MPC Touch User Manual

133
For time divisions larger than 16, the bar’s steps will be represented by
multiple pad banks. Use the left and right arrows (< and >) by the step
numbers (1–16, 17–32, etc.) to change which steps are shown in the
sequencer. The numbers by these arrows indicate which steps are shown.
Alternatively, use Pad Bank Buttons to change which steps are shown.
To adjust the velocities of the steps, do either of the following:
• Tap anywhere on the velocity bar of a step. The top of the velocity bar will jump to that point.
• Use the slider on the right to increase or decrease the velocities of all steps.
Use the Nudge arrows (< and >) to shift each step left or right (respectively) one step. This is useful for
experimenting with different rhythmic permutations.
Use the slider on the right to increase or decrease the velocities of all steps.
Use the Invert button (filled-and-empty-squares icon) to switch which steps have notes
entered and which do not have notes. Steps that previously had no notes will now have
notes at full velocity (127). Steps that previously had notes will now be empty.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
