Akai MPC Touch User Manual

199
Program Edit Mode lets you edit the parameters for each pad.
To select a pad, press it. Its parameters will appear on the screen immediately.
To view a specific tab of parameters, tap the Master, Samples, Pan Velocity, Filter Env, LFO
Modulation, or Effects button on the bottom edge of the touchscreen. You can tap the Samples button
multiple times to cycle through its four available sections.
To turn Loop Lock on or off, tap the Loop Lock button. When on, the loop position is the same as the
pad start (as determined in the third and fourth Samples tabs). When off, the loop position is
independent from the pad start.
Drum Programs
Tap the icon in the upper-right corner to open the Edit Zones
window, which is a feature for drum programs only. This
window displays an overview of any selected pads. Use the
Mode selector to set how the selected pads will be edited:
• Current: Only the currently selected pad can be edited.
• Multiple: All selected pads can be edited simultaneously.
• All: All pads can be edited simultaneously.
Tip: You can immediately select multiple pads while on any
tab in Program Edit Mode (regardless of the current Edit
Zones setting) by pressing and holding the Shift button and
pressing each desired pad. The Edit Zones setting will
automatically change to Multiple.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
