Akai MPC Touch User Manual

185
Pad Mute Mode
Pad Mute Mode lets you easily mute pads within a program or set mute
groups for each pad.
To enter Pad Mute Mode, press Menu, and then tap Pad Mute.
There are two tabs you can view in this mode: Pad Mute or Pad Group. Tap each button in the lower-left
corner to select it. See the following Pad Mute and Pad Group sections to learn about each.
Use the Program field at the top of the touchscreen to select a program.
The counter indicates the current playhead position.
To adjust the position, tap it, and then use the use the Data Dial or the –/+
buttons.
To switch the time increments, double-tap it. You can view it in Bars, Beats,
and Ticks or in hours (HH), minutes (MM), seconds (SS), and frames (FF).
Time Correct lets you quantize pad mutes. This is useful when you want your mutes to line up with a
specific time division. For example, with Time Division set to 1 Bar, your mutes will always align with
the beginning of the measure immediately after you press the pad.
Tap Time Division at the bottom edge of the touchscreen, and select a value from 1/16 to 2 Bars (T
indicates a triplet-based time division).
Tap TC at the bottom edge of the touchscreen to enable or disable the Time Correct feature.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
