Akai MPC Touch User Manual

24
There are two ways to load samples in this mode: using the Project tab or the Samples tab. Let’s try
each of them.
First, load a bass drum using the Project tab:
1. Make sure the Project button in the lower-left
corner of the touchscreen is marked red. If it
isn’t, tap it.
2. Press Pad 1 or tap Pad 1 in the touchscreen to
select it. The pad will be lit green.
3. Use the techniques listed above to find a bass
drum sample you like.
4. To load it to the selected pad (Pad 1, in this
case), either double-tap it, or tap the Load
button in the lower-right corner. Now, you can
press Pad 1 to play the bass drum sample.
Tip: To load an entire folder of samples, press
and hold Shift, and then press Load All.
Next, load a snare drum using the Samples tab:
1. Tap Samples at the bottom of the touchscreen.
This lets you view the pads and project’s sample
pool.
2. Press Pad 2 or tap Pad 2 in the touchscreen to
select it. The pad will be lit green.
3. Use the techniques listed above to find a snare
drum sample you like.
4. To load it to the selected pad (Pad 2, in this
case) double-tap it. Now, you can press Pad 2 to
play the snare drum sample.
To create a simple drum set, repeat the above steps for other pads. We recommend loading a closed hi-
hat and an open hi-hat.
The Project tab in the Browser
The Samples tab in the Browser.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
