Akai MPC Touch User Manual

261
The counter indicates the current playhead position.
To adjust the position, tap it, and then use the use the Data Dial or the –/+ buttons.
To switch the time increments, double-tap it. You can view it in Bars, Beats, and
Ticks or in hours (HH), minutes (MM), seconds (SS), and frames (FF).
Use the Type selector to determine what will be mapped over the pads:
• Notes: Each pad is assigned a note, ascending by one scale degree with each pad.
• Chords: Each pad is assigned a chord, the root note ascending by one scale degree with each
pad. All available chords will play in the key determined by the Scale.
• Chromatic Chords: Each pad is assigned a chord, the root note ascending by one scale degree
with each pad. You can play any chord type regardless of the key determined by the Scale.
Essentially, this is like the Chords setting but with more options to play chords out of the set key.
• Progressions: Each pad is assigned a chord in a chord progression. You can play the pads in (or
out of) order to construct songs quickly. The available chords are determined by the Chord field.
Notes in Pad Perform Mode. Chords in Pad Perform Mode.

Akai MPC Touch Specifications

General

Display type	LED
Built-in display	Yes
Product color	Black
USB direct playback	-
Built-in optical drive	No
Audio (L/R) in	2
Minimum RAM	4 GB
Minimum processor	Dual Core
Minimum processor speed	2.5 GHz
Minimum storage drive space	2048 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8
