7 — 9500 MPR/9500 MPRe port object configuration
7-10 September 2013 Alcatel-Lucent 5620 Service Aware Manager, Release 11.0 R5
3HE 08459 AAAA TQZZA Edition 01
MPR User Guide
5 Expand to the port level and click on a port object. The Physical Port (Edit) form
opens with the General tab displayed.
6 Configure the parameters:
• Current OLC State
• User Label
7 Click on the States tab.
8 Configure the Administrative State parameter.
9 Click on the DS3/E3 tab.
10 Configure the parameters:
• Signal Mode
• Line Code
• AIS Signal Type
11 Click on the other tabs in the properties form to view more port information.
12 Click on the OK button. A dialog box appears.
13 Click on the Yes button. The Physical Port (Edit) form closes.
Procedure 7-6 To configure 9500 MPR AUX alarm ports
This procedure applies only to ports on 9500 MPR, Release 3.0 and later, AUX alarm
cards.
1 Choose Equipment from the navigation tree view selector. The navigation tree
displays the Equipment view.
2 Expand the 9500 MPR NE icon to the MSS shelf level.
3 Right-click on an empty card slot and choose Configure Card from the contextual
menu. The Card Slot - Shelf (Create) form opens with the General tab displayed.
4 Set the Assigned Card Type parameter to AUX and click on the OK button to apply
the changes.
5 Right-click on the AUX alarm card and choose Properties from the contextual
menu. The Card Slot [Port Number], AUX, Shelf (Edit) form opens with the General
tab displayed.
6 Click on the External Point Inputs tab.
Note — Only one AUX alarm card is supported per 9500 MPR MSS shelf.
On the MSS-4 shelf, the AUX alarm card is supported in slot 4. On the
MSS-8 shelf, the AUX alarm card is supported in slot 8.
