Alcatel-Lucent 7210 SAS-T User Manual

7210 SAS-T Overview
7210 SAS-T Installation Guide Page 17
The -48V/+24V/AC LEDs on the left indicate the status of external power. The +12V LED on the
right indicates the status of the internal power conversion process.
Note: You must use AC and/or DC power supplies with your 7210 SAS-T. AC and DC power
supplies can be used simultaneously.
Note: 7210 SAS-T ETR variant must use the 200W power supply when PoE ports are enabled
to supply power to external devices. A maximum of up to 60W power is available for use by
connected PoE devices.
Note: The 7210 SAS-T ETR variant must use a power supply which supports extended
temperature range.
Notes: The +24V DC power module must not be used simultaneously with the -48V DC
power supply.

Alcatel-Lucent 7210 SAS-T Specifications

General

Brand	Alcatel-Lucent
Model	7210 SAS-T
Category	Switch
Language	English
