OmniPCX Enterprise
APPENDIX 2
REMARKS & RESTRICTIONS
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
TC1449 28 Ed. 02 / 22 June 2011
• During the software download operation, you must not try to access to the 2
nd
partition,
otherwise the download process which was running will stop!.
• Patch downloading duration per CS in a common hardware rack is about 1.15 hour/CS
(patch size of 150 MB).
For more information, refer to the technical communication TC0890 OmniPCX Enterprise
download software with OmniVista 4760.
− From Release 7.1, OmniVista 4760 R5.0 application can load MAO logs from PCX.
− OmniVista 4760 R5.0 application forces now a PCX backup whatever the selected mode:
immediate or scheduled.
13.2. OmniVista 4760i
This application is no more supported and can’t be activated anymore. Use mgr or OmniVista 4760
to configure the OmniPCX Enterprise. In case of upgrade to Release 10.0, the application will be
deactivated, if previously activated.
13.3. External Voice Mail
As of Release 10.0, the new parameter Subscription on registration in mgr->
Application ->External Voice Mail object is added.
It must be set to False (Default value) when using external application such as UC R6, ACS, AVST,
…
In case of OXE set using Local Storage Mail box (on OpenTouch Solution), this parameter must be
set to True to allow notification on the OXE set when he receives a new voice message. When OXE
receives the "Register" from Local Storage Voice Mail, a "Subscribe" is sent for the user to receive
notifications.
13.4. SIP Device Management Server
This application needs to be installed on 4760 server. The exact release required depends on the
kind of set to be managed.
It supplies binaries and configuration files to Thomson ST20xx SIP devices (as of 4760 5.0 / SIP DMS
1.0) and to 4008/4018 Extended Edition sets in SIP mode (as of OmniVista 4760 R5.1.06.03.c / SIP
DMS 1.2).
For more detailed information, refer to OmniVista 4760 technical documentation and to technical
communication TC1254 Technical Release Note for Device Management Server 1.2.000.020.
14. CLIP
− CLIP on Z32.
• Calling Line Identification Presentation (CLIP) is only available with analog Z32/eZ32 board
with a Crystal (IP) Media Gateway.
• The protocol ETSI (ETSI 300569 -1/2) and Bellcore (Bellcore TRNWT000030) are supported.
