Alcatel-Lucent OmniPCX Enterprise User Manual

OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
Ed. 02 / 22 June 2011 13 TC1449
4. CONTENT OF THE SOFTWARE PACKAGE
The software package contains the OmniPCX Enterprise J1.410.34.c application.
The different versions of the OmniPCX Enterprise application modules are:
− Linux : 72.0
− Linux Package : 72.3
− swinst : 2.63.0
− PC Installer : 3.2
− OmniPCX Enterprise R10.0: J1.410.34.c: J1.410 complete version
J1.410.34 static patch
J1.410.34.c dynamic patch
SJ1.410.34.c secured patch (Note)
Note
The access to secured patch is only given on request after filing the appropriate document posted on
Business Portal Customer Support > Technical Support > Software download > OmniPCX Enterprise
> OmniPCX Enterprise > All Release > Generic > Request for Security Patch Access.
From Release 6.1.1, dynamic patches will be no more delivered. They are replaced
by static patches; refer to the technical communication TC0682 Stop of dynamic
patch delivery from Release 6.1.1.
Reference of compatible CD-ROMs and DVD
REMINDER
As of Release 6.1, the software is only delivered on DVD.
CD-ROM/DVD Reference MD5 checksums (1)
Version J1.410.34.c (DVD) 3BA 27740 AAAB 62fda425d70025a35c048e907d15faf2
*Image_R100_J141034c.iso
Secured Version SJ1.410.34.c
(DVD)
3BA 27741 AAAB 85adb9c5c518371fd92fff19fb714250
*Image_R100_SJ141034c.iso
System voice guides v5.3 3BA 57423 AAAG
OmniVista 4760 R5.2.01.03.d 3BH 11632 AKAA 4bf879c27952dd851462a8412fde6a19
*CD Version R5.2.01.03.d.iso (2)
OmniVista 8770 R1.0.20.01.b 3BH 11669 AAAC (3)
SIP Device Management Server
1.2.000.020 – Release 1.2
3BH 11761 AAAD 392937c3530b40f1101d040631483065
*image_dm_12000020.iso
(1) Before installing the software, we strongly advise you to check the integrity and authenticity of the
software. For detailed information about checksums, please refer to the technical communication
TC1271 Checks for integrity and authenticity of downloaded software.
(2) This checksum concerns only the DVD containing the OmniVista 4760 software Release
R5.2.01.03.d reference 3BH 11628 AMAA.

Alcatel-Lucent OmniPCX Enterprise Specifications

General

VoIP Protocols	SIP, H.323
Type	IP PBX
VoIP Codecs	G.711, G.729
Integration	CRM
Security	TLS, SRTP
Management	Web-based management
Redundancy	Yes, with redundant CPU and power supply

Summary

Introduction to Release 10.0

New hardware

New features

Overview of new functionalities and enhancements in Release 10.0.

Content of the Software Package

Before Starting

Applications and Functionalities Not Supported by Release 10.0

Lists applications and functionalities no longer supported in Release 10.0.

Applications and Functionalities Dependent on CPUs and Hardware Platform

Compatibility of applications with specific CPU and hardware platforms.

VoIP Network Conformity Check

Recommendations and Security

Conditions for Installation in Network

Network Interworking Rules

Installation of Release 10.0 in Network with Releases 5.1.x, 6.x, 7.x and 8.0

Installation of Release 10.0 in Network Releases 8.0.1, 9.0 and 9.1

Compatibilities

Reminder on Boards Supporting the Transit Function and Direct RTP

Information on boards supporting transit function and direct RTP.

Delay (in one direction) Introduced by IP Gateways

Delay (in one direction) from an IP Phone towards a Set behind ACT or eMG

ABC-F2 Compatibility Depending on Hardware and Configuration

ABC-F2 compatibility based on hardware and voice compression.

Network & VoIP Compatibility

ABC-F2 Trunk Group Compatibility Summary

Summary of ABC-F2 trunk group compatibility across releases.

Number of Compressors/Algorithms for INTIPx and GDx/GAx

Alcatel-Lucent 4635 Voice Mail Compatibility

Hardware Compatibility

CPU Boards

Compatibility details for various CPU boards.

Common Hardware CPU Boards

Compatibility of common hardware CPU boards.

Appliance Server

Supported Alcatel-Lucent recommended Appliance Servers.

Hard Disk Capacity

INTIP Board

NGP Boards

Subdevices & IP Phone Compatibility

Application Compatibility

OEM/External Equipment Compatibility

Client Information

Preparation

Checking Compatibility

Review applications, hardware, and functionalities before version change.

Saving the Database (swinst)

Rebuilding the Database Before Saving

Procedure for rebuilding the database before backup.

Saving the Rebuilt Database

Operating Mode

Updating R5.1.x, R6.x, R7.x, R8.0.x, R9.x to R10.0

Steps and considerations for updating to Release 10.0.

OmniPCX 4400 Migration to R10.0

Use of the Hardware or Software Key

Loading the Software

Security Activated by Default During Installation

Security level options during initial system installation.

Installation of a Secured System for VoIP Encryption

Procedure for installing IP Touch Security service for VoIP encryption.

Reading the Hardware Key or CPU-id of the CPUs

Restoring the Database and Site Tickets

Installing OPS Files

System Management

Declaring the Automatic Start-up of the Telephone

Checking Start-up of CPU/IO1/IO2/IO2N

Compulsory Minimum Additional Database Management

IP Addressing Plan (from R3.0)

IP Routing (from R3.0)

Reminder for Networked Sites Migrating from Release < 7.x

Synchronization

System Parameters to Check

Direct RTP

Checking the Direct RTP parameter setting.

Frame VoIP (Enhanced Quality Voice)

Direct RTP for H323 Terminals

Inter-node Protocol H323

Starting Up the CPU in its Environment on Site

Downloading the Couplers and Sets

Procedure for downloading new firmware to couplers and sets.

Sites with the "IP Touch Security" Feature

Procedure for updating IP Touch security boxes with specific patch.

Checking Correct Operation

Appendix 1: New Hardware and Features

New Hardware and Features from Release 10.0

Details on new hardware and features introduced in Release 10.0.

SIP TLS/sRTP for External SIP Gateway

Security protocols for SIP communications with external gateways.

Appendix 2: Remarks & Restrictions

System

Communication Servers

Spatial Redundancy

IP Crystal Media Gateway

Media Gateway

VoIP

VoIP features, echo delay, LIOE, Direct RTP, and QoS.

ABC-F IP Trunk Group

SIP

Sets

Compatibility and features of IP Phone V1/V1S and Series 8/9 sets.

MIPT 300&600 Handsets

DECT

IP Touch Security Feature

Installation of secured patches for IP Touch security.

Applications

CLIP

Directory

Boards
