OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
TC1449 36 Ed. 02 / 22 June 2011
INTIP3A boards provide up to 120 compressors. If Soft-MSM feature is used, then the maximum
number of compressor is 60.
The V24 console cable for NGP boards is the same as the one used for CS / GD boards.
GD3, GA3, PowerMEX are authorized only in shelves with external battery (rule
taken into account by Actis 15).
In case of shelves with internal battery, Actis will continue to configure GD/GA/MEX
boards.
References of the current Common Hardware media Gateway shelves without internal battery:
Designation Reference
Rack module 1 - 110V/230V (without internal battery) 3BA 00404 AB
Rack module 1 - 48V (without charger & battery) 3BA 00404 AV
Rack module 3 - 230V (without internal battery) 3BA 00406 AB
Rack module 3 - 48V (without charger & battery) 3BA 00406 AV
The USB connector, present on NGP boards, is not taken into account by the board binary.
NGP boards provide two 10/100/1000 Base-T connectors. Either Ethernet connector can be used
but not both in the same time: currently Ethernet redundancy is not available on NGP boards.
The DIP switch on the NGP boards has not to be modified. The only reason for
which it could be modified on GD/GA boards was to enter in LOLA mode: with NGP
boards, this mode is useless as a flash format is automatically performed when a
network boot is done. Besides this component is quite fragile.
7.7.9 INT1/INT2 boards
In Release 10.0, INT1and INT2 boards must be replaced by INTOF/INTOF2 boards.
7.7.10 Negotiation of speed of Ethernet interfaces
Refer to the technical communication TC0680 Risk of wrong negotiation of speed and duplex mode
of Ethernet interfaces for INTIPs, GA & GD after software upgrades.
