OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
APPENDIX 2
REMARKS & RESTRICTIONS
Ed. 02 / 22 June 2011 3 TC1449
1. SYSTEM
− Bios for Call Server CPU-CS.
As of Release 5.1, the Call Server (CS board) Bios version is higher than 8.17.
This version allows access to certain Bios functions (the main one being the Ethernet boot) which
could not be accessed from the R5.0 Lx since only R&D knew the password.
When booting the CS board:
• press Ctrl B then Ctrl I,
• the system requests a password (Warning: it is empty!) press <Enter>,
• a "light" Bios menu is displayed which allows an Ethernet boot to be carried out, the MAC
address of the board to be displayed, etc.
Bios menu
"
YOU CAN strike Ctrl B to enter in BIOS monitor during several seconds from
NOW !
hit [Ctrl I] for BIOS monitor!
Password?: (password to access the light menu)
Alize BIOS Monitor
*** BIOS Version 3EH30227DRAA bios100/008.017 ***
*** Generated on Jun/13/2003 at 09:25 ***
Monitor Light Menu
01 - Load From Hdisk #0
02 - Load From Ethernet
03 - Load From Flash NAND program
04 - Load From Flash NAND program and Bootp
05 - Load From Hdisk #0 and Bootp
06 - Display MAC address
07 - Display PCMS id
08 - Display System informations
09 - Full Options menu (Reserved for R&D)
10 - Reset System
"
− BIOS for Call Server CPU-CS-2.
To access the BIOS of the CPU-CS-2 board, when booting the board:
• press Ctrl B
• a "graphical" AMI Bios menu, similar to the one use in PC, is displayed
