OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
APPENDIX 2
REMARKS & RESTRICTIONS
Ed. 02 / 22 June 2011 13 TC1449
6. MEDIA GATEWAY
6.1. GD/GA boards
− Direct connectivity of the Ethernet port of these boards to a port of a switch is mandatory.
− By default, dynamic IP addressing is active (DHCP) on a GD board.
− The GA board does not support DHCP feature.
− If the GD supports H323 links, a static IP address must be assigned to the GD.
− Now the maximum duration for the GD software downloading is manageable from eMG
binaries:
• 16.34 (E2.504.1.r)
• 22.7 (F1.603.1.h)
• 30.9 (F2.500.6.e)
• 40.5.1 (F3.301.9)
By default, the timeout is 20 min. AT the end of this timeout, the GD restarts with its previous
software.
− Due to the possibility of the GD to encrypt directly its signaling link, two versions of GD binaries
are available from Release 9.0: one containing the encryption mechanisms and one without. As
for the IP Touch sets since Release 6.2, the generic OmniPCX Enterprise versions provide the
binaries without the encryption mechanisms, whereas the binaries with these mechanisms will be
available in the corresponding secured patch.
− GD/GA binaries (secured or not) are systematically signed. This information is verified only on
PBX in protect mode.
6.2. INTIPB board
In the document the name "INTIPA or B" concerns the INTIP board as well the INTIP2 board
− Direct connectivity of the Ethernet port of the INTIPB board to a port of a switch is mandatory.
− The INTIPB board supports 10/100Mb/s and Half/Full Duplex mode.
− The mode Full-Duplex or Half-Duplex (default mode) of the INTIPB must be configured via the
V24:
• If the switch is in auto-negotiation, the switch will operate in the mode configured in the
INTIPB.
• If the switch is configured in Full-Duplex, the INTIPB must be configured in Full-Duplex too.
• If the switch is configured in Half-Duplex, the INTIPB must be configured in Half-Duplex too.
− To configure the INTIPB in static IP addressing mode or Half/Full, you must use the cable 3BA
28112 for INTIP board and the cable 3EH 75003 AAAA for the INTIP2 board.
− The INTIPB board must not be used for H323 links or IP Phones handling.
