OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
APPENDIX 2
REMARKS & RESTRICTIONS
TC1449 12 Ed. 02 / 22 June 2011
5. IP CRYSTAL MEDIA GATEWAY
In the document the name "INTIPA or B" concerns the INTIP board as well as the INTIP2 board.
− Only one Voice Hub or M1 or M2 cabinet is supported for the IP Crystal Media Gateway in the
main zone.
− The GPA2 is supported in the IP Crystal Media Gateway.
− In peripheral zone all 4400 boards are supported.
− INTIP board cannot be used with embedded Ethernet (a CBC1 10/100 connector must be used).
− INTIPA board can be used with 100 Mbits. With a VH cabinet you have to use the Patch Panel
10/100Mbits Reference 3BA 23244 AAAA 01.
− 100 Mbits compliance with WM1 and VH cabinets for CPU6 Step2 and CPU7.
The CPU7 board is not allowed in a VH cabinet.
All cabinets are or will be compatible with 10/100BaseT. The VH and WM1 cabinets compatible
10/100BaseT will be available soon with the following references:
Designation Reference
VH (10/100BaseT) Basic Rack 48V 3BA 56191 AN
VH (10/100BaseT) Basic Rack 48V - USA 3BA 56191 UN
VH (10/100BaseT) Basic Rack 90W 3BA 56193 AN
VH (10/100BaseT) Basic Rack 90W - USA 3BA 56193 UN
VH (10/100BaseT) Extension Rack 48V 3BA 56192 AN
VH (10/100BaseT) Extension Rack 48V - USA 3BA 56192 UN
VH (10/100BaseT) Extension Rack 90W 3BA 56194 AN
VH (10/100BaseT) Extension Rack 90W - USA 3BA 56194 UN
WM1 (10/100BaseT) Basic Packed 110/230V 3BA 27112 AN
WM1 (10/100BaseT) Basic Packed 110/230V - USA 3BA 27112 UN
WM1 (10/100BaseT) Basic Packed 48V 3BA 27113 AN
WM1 (10/100BaseT) Basic Packed 48V - USA 3BA 27113 UN
WM1 Battery package (battery autonomy 1.2 Ah) 3BA 57106 AC
WM1 Battery package (battery autonomy 1.2 Ah)- USA 3BA 57106 UB
Note
If the referenced cabinets above are not used, the CPU6 Step2 and CPU7 boards will work at 10
Mbits maximum.
