OmniPCX Enterprise
INSTALLATION PROCEDURE FOR VERSION
J1.410.34.c – RELEASE 10.0
APPENDIX 2
REMARKS & RESTRICTIONS
Ed. 02 / 22 June 2011 15 TC1449
NGP binaries (secured or not) are systematically signed. This signature is verified in all cases by Call
Server (mode protect or bypass).
Resources provisioning on Common Hardware NGP boards:
Armada
daughter
board
Compressors N-way conferences Voice Guide
access
3-way conf DTMF
receivers
No 15
1x7, 2x7, 3x7, 4x7 or
1x15, 2x15 or 1x30
16 24 30
No 30 0 16 24 30
Yes 45
1x7, 2x7, 3x7, 4x7 or
1x15, 2x15 or 1x30
16 24 30
GD-3 mix
Yes 60 0 16 24 30
GA-3 N-conf No 0 4x7 or 2x15 or 1x30 16 3 0
No 15 1x7, 2x7, 3x7 or 1x15
16 3 0
No 30 0 16 3 0
Yes 30 3x7, 4x7, 2x15 or
1x30
0 0 0
GA-3 mix
Yes 45 1x7, 2x7 or 2x15 0 0 0
GA-3 VoIP Yes 60 0 0 0 0
GA-3 3-conf No 0 0 0 21 0
PowerMex N/A N/A N/A 0 24 30
The account root has to be used to enter the console of a NGP board. The account admin exists but
doesn’t allow doing anything.
To reload from scratch a binary in a GD3/GA3/INTIP3 board, just use PC Installer in version 2.26
and perform a network boot of the board: it will automatically reformat its flash and then download
the various binary files. The LOLA mode, used for GD/GD2 boards is no more necessary as the
flash reformat is performed automatically. A reboot of the NGP board is mandatory after the
flashing process.
To enter the BIOS of a GD3, GA3 or INTIP3, as for a GD board, the sequence Ctrl-B Ctrl-I has to be
done (rather quickly for NGP).
U-Boot 1.3.0-rc3 (Apr 15 2009 - 16:37:27) 3EH30350AAAI bootl100/000.008
Reset Status: Software Hard, External/Internal Soft, External/Internal Hard
CPU: e300c4, MPC8377, Rev: 21 at 399.999 MHz, CSB: 266 MHz
I2C: ready
DRAM:
DDR DIMM: data bus width is 64 bit without ECC
DDRC ECC mode: OFF
DDR RAM: 256 MB
FLASH: 2 MB <---------------- Press quickly Ctrl-B Ctrl-I immediately after this info
PCI: Bus Dev VenId DevId Class Int
00 17 1064 2102 0000 00
In: serial
Out: serial
Err: serial
Net: TSEC0, TSEC1
