Alcatel-Lucent OmniSwitch AOS Release 7 - Port Mirroring Overview

Diagnosing Switch Problems Port Mirroring Overview
OmniSwitch AOS Release 7 Network Configuration Guide March 2011 page 26-3
Port Mirroring Overview
The following sections detail the specifications, defaults, and quick set up steps for the port mirroring
feature. Detailed procedures are found in “Port Mirroring” on page 26-14.
Port Mirroring Specifications
Port Mirroring Defaults
The following table shows port mirroring default values.
Global Port Mirroring Defaults
Platforms Supported OS10K
Ports Supported Ethernet (10 Mbps)
Fast Ethernet (100 Mbps)
Gigabit Ethernet (1000 Mbps)
10 Gigabit Ethernet (10000 Mbps)
Maximum Combined Local and Remote
Mirroring Sessions Supported
2
N-to-1 Mirroring Supported 128 to 1
Number of RPMIR VLANs per session 1
Parameter Description CLI Command Default Value/Comments
Mirroring Session Creation port-mirroring source destination No Mirroring Sessions
Configured
Protection from Spanning Tree
(Spanning Tree Disable)
port-mirroring source destination Spanning Tree Enabled
Mirroring Status Configuration port-mirroring source destination Enabled
Mirroring Session Configuration port-mirroring Enabled
Mirroring Session Deletion port-mirroring No Mirroring Sessions
Configured
