Publication 1394-5.0 — May 2000
Preface P-3
Related Documentation
The following documents contain additional information concerning
related Allen-Bradley products. To obtain a copy, contact your local
Allen-Bradley office or distributor.
Conventions Used in this Manual
The following conventions are used throughout this manual:
• Bulleted lists such as this one provide information, not procedural
steps.
• Numbered lists provide sequential steps or hierarchical
information.
• Words that you type or select appear in bold.
• When we refer you to another location, the section or chapter
name appears in italics.
Module Series Designator
To determine the series designator, check the series field on the Allen-
Bradley label attached to your system, axis, and shunt modules. The
series designator is located as shown in the example below.
Figure P.1
Allen-Bradley Label
For: Read This Document: Document Number:
A description and specifications for the 1394 family 1394 Digital, AC, Multi-Axis Motion Control
System Product Data
1394-2.0
A description and specifications for the 1326A Torque Plus
Motors used with the 1394
1326AB 460V, Torque Plus Series, AC Servo
Motors Product Data
1326A-2.9
A description and specifications for the 1326A Rare Earth
Motors used with the 1394
1326AS Series 460V, Low Inertia, Brushless
Servo Motors Product Data
1326A-2.10
Product information regarding cables used with the 1326AB and
1326AS motors
1326 Cables for 460V AC Servo Motors 1326A-2.11
A user guide for GML
programming to be used with the 1394
GMC System.
GML Commander Reference Manual GMLC-5.2
An overview of the Flex I/O
products Flex I/O Product Profile 1794-1.14
Specifications for the Flex I/O products Flex I/O Product Data 1794-2.1
An overview of the PanelView
550/600 product PanelView 550/600 Product Profile 2711-1.13
An overview of the 9/Series products 9/Series CNC Product Profile 8520-1.3
A manual that provides you information on RIO communications Installation Guidelines for the Twinaxial Cable 92-D1770-BCO
A manual that assists you with integrating and maintaining the
9/Series to be used with the 1394 CNC Interface System
9/Series Integration and Maintenance Manual 8520-6.2
An article on wire sizes and types for grounding electrical
equipment
National Electrical Code Published by the National Fire
Protection Association of Boston, MA.
A glossary of industrial automation terms and abbreviations Allen-Bradley Industrial Automation Glossary AG-7.1
1394 Digital Servo Controller
300W Shunt Module
BULLETIN 1394 300W SHUNT MODULE
ALLEN-BRADLEY
FOR USE WITH 1394-SJT22-X SYSTEM MODULE
CAT. PART SER.
INPUT DC INPUT AC
FOR FUSE REPLACEMENT USE:
BUSSMAN CAT. NO.
R
BULLETIN 1394 300W SHUNT MODULE
BULLETIN 1394 300W SHUNT MODULE
ALLEN-BRADLEY
FOR USE WITH 1394-SJT22-X SYSTEM MODULE
CAT.
PART
SER.
INPUT DC
INPUT AC
FOR FUSE REPLACEMENT USE:
FOR FUSE REPLACEMENT USE:
BUSSMAN CAT. NO.
R
Series Field
Shunt Module Example
