Allen-Bradley 1394 User Manual

Publication 1394-5.0 — May 2000
A-4 Specifications
DC Link Module
The table below lists the specifications for the DC Link Module.
Drive Interface Module
The table below lists the specifications for the Drive Interface
Module.
Filters
The table below shows the requirements for filters that you can use.
The: For the 1394-DCLM is:
Firmware version 5.0 or higher with 1394
x -SJT xx -A systems
3.7 or higher with 1394
x -SJT xx -C- xx and -T- xx systems
3.9 or higher with 1394C-SJT
xx -L- xx systems
Software GML Commander, version 4.02 or higher
Input voltage 530/680V DC, single phase
Current Continuous (rms) 32A, Peak (rms - 1 second) 200A
Capacitance 990 µF
Energy storage 7.36 joules based on a nominal 50V bus delta
Cables available (part numbers) 1394-CPDC-0015 and 1394-CPDC-0030
Cable lengths available 1.5 m (4.92 ft) or 3 m (9.84 ft)
Operating temperature 0
° to 50 ° C (32 ° to 122 ° F)
Relative humidity 5-95%, non-condensing
Weight 4.8 kg (10.5 lbs)
The: For the 1394-DIM is:
Firmware version 3.7 or higher with 1394
x -SJT xx -C- xx and -T- xx systems
3.9 or higher with 1394C-SJT
xx -L- xx systems
Software GML Commander, version 4.01 or higher
Input voltage 24V, 50 kHz provided by the 1394
x -SJT- xx system module
Analog output information
(P
x -1,2)
Voltage 0 to ± 10V analog
Signal isolation 1500V rms
Resolution 12 bits, 4.88 mV
Impedance 220 ohms
Offset ± 80 mV maximum, compensated to 0 through software setup
Drive OK 15V DC @ 5 mA supplied by the DIM
Drive enable output 30V DC @ 1 A
Operating temperature 0
° to 50 ° C (32 ° to 122 ° F)
Relative humidity 5-95%
Weight 3 kg (6.6 lb)
The: For the SP-74102-006-01 is: For the SP-74102-006-02 is: For the SP-74102-006-03 is:
Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Voltage 460V AC 460V AC 460V AC
Current 23A @ 50
° C (73.4 ° F) 30A @ 50 ° C (86 ° F) 75A @ 50 ° C (122 ° F)
Operating Temperature -25
° to 85 ° C (-13 ° to 185 ° F) -25 ° to 85 ° C (-13 ° to 185 ° F) -25 ° to 85 ° C (-13 ° to 185 ° F)
Vibration 10-200 Hz @ 1.8 g 10-200 Hz @ 1.8 g 10-200 Hz @ 1.8 g
Humidity 90% 90% 90%
Weight 1.6 kg (4.16 lb) 2.7 kg (7.02 lb) 5.2 kg (13.52 lb)
Power Loss 20W 38W 57W
Roxburgh Catalog No. MIF323-GS MIF330-GS MIF375-GS
