Publication 1394-5.0 — May 2000
Using the Human Interface Module (HIM) C-15
8. Press ENTER. The following message appears:
9. Press SEL. The cursor moves to the bottom line.
10. Press either the up or down arrow key until the following appears:
11. Press ENTER. The system records your choice and the cursor
moves to the top line.
12. Press ESC. Press the up or down arrow key until the following
appears:
13. Press ENTER. The system records your choice and a message
similar to the following appears:
14. Press ENTER. The system saves the values that you entered and
the following message appears:
15. Remove power.
16. Remove cable from the HIM.
Setting Up the HIM for Hand-Held Use
To prepare the HIM for hand-held use:
1.
2. Connect the appropriate cable between the HIM and the
communications port.
Note: A second SCANport connection is available
(communications port 2) at the bottom of the system
module. This port can also be used for a hand-held HIM.
3. Apply power.
Control Logic
Enabled
Control Logic
Disabled
Choose Mode
EEPROM
EEPROM
Save Values
Choose Mode
EEPROM
If you are
setting up:
Do this:
A new HIM Go to step 2 below.
A HIM that is
currently in the
HIM cradle
1. Remove the HIM from the HIM cradle using
the steps in the Removing the HIM from the
HIM Cradle section.
2. Complete the steps in the Disconnecting the
HIM from the System Module section.
3. Go to step 2 below.
