Publication 1394-5.0 — May 2000
C-8 Using the Human Interface Module (HIM)
Copying a System’s Information
Note: These steps assume that you are starting from the top level of
the HIM (Sys Wait Bus).
To copy a drive’s information using Copy Cat:
1. At the HIM, press ENTER. A message similar to the following
appears:
2. Press either the up or down arrow key until the following appears:
3. Press ENTER. The system records your choice and a message
similar to the following appears:
4. Press either the up or down arrow key until the following appears:
5. Press ENTER. The system records your choice and the following
message appears:
Note: You can store up to two sets of system/drive information in
the HIM at one time. The 1 in the example above means
that this is copy number 1.
6.
7. Press SEL. A message similar to the following appears:
Note: The A represents the symbols that you can use to give this
copy a name.
8. Press either the up or down arrow key until the location in which
the A originally appeared becomes the first letter of the name that
you want this copy to have.
9. Press SEL. The letter is selected, appears on the display and
another A appears next to it.
Choose Mode
Display
Choose Mode
EEPROM
EEPROM
Save Values
EEPROM
Drive -> HIM
Drive -> HIM
1
If you want to use
location:
Press either the up or down arrow key
until:
1 A 1 appears on the bottom.
2 A 2 appears on the bottom.
Drive -> HIM
1 A
To Next Page
