212 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Appendix B CIP Information
The following common services will be implemented for the Analog Output
Point Object:
Parameter Object
CLASS CODE 0x000F
The following class attributes will be supported for the Parameter Object:
The number of instances of the parameter object will depend upon the type of
Distributed Starter that the control board is connected to.
The following instance attributes will be implemented for all parameter
attributes:
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT —
2 Get Max Instance UINT —
8 Get Parameter Class Descriptor WORD —
9 Get Configuration Assembly Instance UINT
100 for Bulletin 290E/291E units
101 for Bulletin 294E units
Attribute ID Access Rule Name Data Type Value
1 Get/Set Value Specified in Descriptor —
2 Get Link Path Size USINT —
3 Get Link Path
Array of:
BYTE
EPATH
—
4Get DescriptorWORD —
5Get Data TypeEPATH —
6Get Data SizeUSINT —
7 Get Parameter Name String SHORT_STRING —
8 Get Units String SHORT_STRING —
9 Get Help String SHORT_STRING —
10 Get Minimum Value Specified in Descriptor —
11 Get Maximum Value Specified in Descriptor —
12 Get Default Value Specified in Descriptor —
13 Get Scaling Multiplier UINT —
14 Get Scaling Divisor UINT —
15 Get Scaling Base UINT —
16 Get Scaling Offset INT —
