170 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Chapter 6 Specifications
Motor Overload Trip Curves
Class 10
% Full Load Current
Approximate Trip Time [s]
Cold
Hot
Class 15
% Full Load Current
Approximate Trip Time [s]
Cold
Hot
Class 20
% Full Load Current
Approximate Trip Time [s]
Cold
Hot
