Appendix B CIP Information
The following common services will be implemented for the TCP/IP Interface
Object.
Ethernet Link Object
CLASS CODE 0x00F6
The following class attributes will be supported.
Two instances of the Ethernet Link Object will be supported.
5 Get/Set Interface Configuration Struct of:
UDINT
UDINT
UDINT
UDINT
UDINT
STRING
IP Address
Network Mask
Gateway Address
Primary DNS
Secondary DNS
Default Domain Name for not fully qualified host names
6 Get/Set Host Name STRING
8 Get/Set TTL Value USINT Time to Live value for EtherNet/IP multicast packets
9 Get/Set Multicast Config Structure of
USINT
USINT
UINT
UDINT
Allocation Control
Reserved
Number of multicast addresses to allocate (1-4)
Multicast starting address.
10 Get/Set SelectAcd BOOL Activates the use of ACD
11 LastConflictDetected Structure of
USINT
USINT(6)
USINT(28)
AcdActivity
RemoteMAC
ArpPdu
Attribute ID Access Rule Name Data Type Value
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x4C No Yes Get_And_Clear
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 3
2 Get Max Instance UINT 2
3 Get Number of Instances UINT 2
Attribute ID Access Rule Name Data Type Value
1 Get Interface Speed UDINT 10 or 100 Mbit/Sec
2 Get Interface Flags DWORD See ENet/IP Specification
3 Get Physical Address ARRAY of 6 USINTs MAC Address
