Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 193
Appendix B
CIP Information
High Level Product
Description
The ArmorStart LT EtherNet/IP is an extension of the ArmorStart LT
DeviceNet. Three product types offered:
Product Codes and Name Strings
The following table lists the product codes and name strings that will be added to
the ArmorStart LT product family for EtherNet/IP.
Table 31 - ArmorStart LT Distributed Starter Type
Bulletin Number Distributed Starter Type
290E DOL
291E Reversing
294E V/Hz
Table 32 - Product Codes and Name Strings
Product
Code
Current
Rating Identity Object Name String
Integrated
Power Supply
0x301 0.24…3.5 amps ArmorStart 290E 0.24…3.5 A No
0x302 1.1…7.6 amps ArmorStart 290E 1.1…7.6 A No
0x311 0.24…3.5 amps ArmorStart 290EP 0.24…3.5 A Yes
0x312 1.1…7.6 amps ArmorStart 290EP 1.1…7.6 A Yes
0x341 0.24…3.5 amps ArmorStart 291E 0.24…3.5 A No
0x342 1.1…7.6 amps ArmorStart 291E 1.1…7.6 A No
0x351 0.24…3.5 amps ArmorStart 291EP 0.24…3.5 A Yes
0x352 1.1…7.6 amps ArmorStart 291EP 1.1…7.6 A Yes
0x3C2 0.5…2.5 amps ArmorStart 294E 0.5 Hp No
0x3C4 1.1…5.5 amps ArmorStart 294E 1.0 Hp No
0x3C6 3.2…16 amps ArmorStart 294E 2.0 Hp No
0x3D2 0.5…2.5 amps ArmorStart 294EP 0.5 Hp Yes
0x3D4 1.1…5.5 amps ArmorStart 294EP 1.0 Hp Yes
0x3D6 3.2…16 amps ArmorStart 294EP 2.0 Hp Yes
