Allen-Bradley ArmorStart 294E User Manual

Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 111
Bulletin 290E/291E/294E Programmable Parameters Chapter 4
Basic Configuration Group
SnapShotLAvgAmps
This parameter provides a snapshot of
average of 3 Phase currents at time
of last trip.
Parameter Number 26
Access Rule GET
Data Type INT
Group Trip Status
Units x.xx Amps
Minimum Value 0
Maximum Value 32767
Default Value 0
SnapShot%Thermal
This parameter provides a snapshot of the
percentage of Thermal Capacity used at
time of last trip.
Parameter Number 27
Access Rule GET
Data Type USINT
Group Trip Status
Units Percent
Minimum Value 0
Maximum Value 100
Default Value 0
FLASetting
The motor’s full load current rating is
programmed in this parameter.
Parameter Number 28
Access Rule GET/SET
Data Type INT
Group Basic Configuration
Units x.xx Amps
Minimum Value See Table23.
Maximum Value See Table23.
Default Value See Table23.
Table 23 - FLA Setting Ranges and Default Values (with indicated setting precision)
FLA Current Range (A)
Default Value
CatNo 460V AC Minimum Value Maximum Value
290E/1_-FA_* 3 Hp 0.24 3.5 0.24
290E/1_-FB_* 5 Hp 1.1 7.6 1.1
