Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 223
CIP Information Appendix B
TCP/IP Interface Object
CLASS CODE 0x00F5
The following class attributes will be supported.
One Instance of the TCP/IP Interface Object will be supported.
4Warning 4 —
5 Warning 5 Indicates missing supply phase. This fault can be disabled.
6 Jam Warning Motor current has exceeded jam warning level.
7 Underload Warning Motor current dropped below Underload Warning level.
8Warning 8 —
9Warning 9 —
10 Warning 10 —
11 Warning 11 —
12 Warning 12 —
13 Switched Pwr Warn Indicates the control power has dipped below 19 Volts.
Not available in units with Integrated Power Supply.
14 Under Power Warn Indicates the internal power supply is below its optimal level.
Available in units with Integrated Power Supply only.
15 Warning 15 —
16 Warning 16 —
17 Warning 17 —
18 Warning 18 —
19 Warning 19 —
20 Warning 20 —
21 Aux Power Warn Indicates auxiliary Power was has dipped below 19 Volts.
Not available in units with Integrated Power Supply.
Table 35 - Fault Codes, Fault Text, and Fault Help Strings for ArmorStart LT
Warning
Code Warning Text Help Text
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
Attribute ID Access Rule Name Data Type Value
1GetStatus DWORD
2 Get Configuration Capability DWORD 0x000000F4
3 Get/Set Configuration Control DWORD 0 = Configuration from NVS
2 = Configuration from DHCP
4 Get Physical Link Object Struct of:
UINT
Padded EPATH
2 words
20 F6 24 01 (Enet Link Object Instance 1)
