Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 23
Product Overview Chapter 1
ArmorStart LT Characteristics
Figure 4 - Bulletin 290E/291E ArmorStart LT
6 Configurable I/Os
LockOut/TagOut Provision
Wiring Access
Reset
IP Address Switches
1
On
0
O
On/Off Switch
HOA Keypad (optional)
Gland Plate – Conduit/Cord Grip or
ArmorConnect
®
Media (optional)
Status and Diagnostic LEDs
Dual Port EtherNet/IP
(This is replaced by a DeviceNet connector,
when DeviceNet communication is selected)
ECM (Electronic
Control Module)
Protective Earth (PE)
