218 Rockwell Automation Publication 290E-UM001B-EN-P - June 2012
Appendix B CIP Information
A single instance (instance 1) will be supported.
The following common services will be implemented for the Extended Device
Object.
DPI Fault Object
CLASS CODE 0x0097
This object provides access to fault information within the device.
The following class attributes will be supported for the DPI Fault Object.
Attribute ID Access Rule Name Data Type Value
1 Set Name STRING User Assigned Name – Defaults to a null. 32 chars max
2 Set Description STRING User Assigned Description – Defaults to a null. 64 chars max
3 Set Geographic Location STRING
User Assigned Geographic Loc. – Defaults to null. 32 chars
max
101 Set Contacxts 1 STRING Contacts String – Defaults to a null. – 80 chars max.
102 Set Contacts 2 STRING Contacts String – Defaults to a null. – 80 chars max.
Service Code
Implemented for:
Service NameClass Instance
0x01 No Yes Get_Attribute_All
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Class Revision UINT 1
2 Get Number of Instances UINT 4
3 Get/Set Fault Cmd Write USINT 0=NOP; 1=Clear Fault; 2=Clear Flt Queue
4 Get Fault Instance Read UINT
The instance of the Fault Queue Entry containing information
about the fault that tripped the device.
5 Get Fault into parameter instance array
Struct of:
UINT
Array [5] of UINT
Array of SnapShot parameter instance numbers
Array Size = 5
Array of Instance Numbers = 23,24,25,26,27
6 Get Number of Recorded Faults UINT The number of faults recorded in the fault queue.
