Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 213
CIP Information Appendix B
The following services will be implemented for the Parameter Object:
Parameter Group Object
CLASS CODE 0x0010
The following class attributes will be supported for the Parameter Group Object:
The following instance attributes will be supported for all Parameter Group
Instances.
The following common services will be implemented for the Parameter Group
Object.
17 Get Multiplier Link UINT —
18 Get Divisor Link UINT —
19 Get Base Link UINT —
20 Get Offset Link UINT —
21 Get Decimal Precision USINT —
Attribute ID Access Rule Name Data Type Value
Service Code
Implemented for:
Service NameClass Instance
0x01 No Yes Get_Attribute_All
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x4b No Yes Get_Enum_String
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT —
2 Get Max Instance UINT —
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING —
2 Get Number of Members UINT —
3Get 1st Parameter UINT —
4 Get 2nd Parameter UINT —
n Get Nth Parameter UINT —
Service Code
Implemented for:
Service NameClass Instance
0x01 Yes Yes Get_Attribute_All
0x0E Yes Yes Get_Attribute_Single
