Rockwell Automation Publication 290E-UM001B-EN-P - June 2012 107
Bulletin 290E/291E/294E Programmable Parameters Chapter 4
Trip Status Group
OutputSourceV (IPS)
[SwitchedVolts]
This parameter determines the incoming
switched control voltage across terminals
A1…A2.
(IPS) Available voltage on User Output Pin
4 for all I/O points
Parameter Number 11
Access Rule GET
Data Type UINT
Group Basic Status
Units x.xx Volts
Minimum Value 0
Maximum Value 65535
Default Value 0
SensorSourceV (IPS)
[UnswitchedVolts]
This parameter determines the incoming
unswitched control voltage across
terminals A2…A3.
(IPS) Available voltage on Input Sensor
Source Pin 1 for all I/O points
Parameter Number 12
Access Rule GET
Data Type UINT
Group Basic Status
Units x.xx Volts
Minimum Value 0
Maximum Value 65535
Default Value 0
TripStatus
This parameter provides the fault
condition that caused any current trip.
Parameter Number 16
Access Rule GET
Data Type WORD
Group Trip Status
Units —
Minimum Value 0
Maximum Value 0xE3BF
Default Value 0
